P30
PERFORMANCE SERIES
ACTIVE VOCAL MICROPHONE
P30
PERFORMANCE SERIES
ACTIVE VOCAL MICROPHONE
P30
PERFORMANCE SERIES
ACTIVE VOCAL MICROPHONE
Features:
- DynamicDrive technology for electronically optimized output
- Custom-tuned, premium vocal performance capsule
- Internal capsule shock-mount suspension system
- Rugged, reinforced mesh grille
- Ergonomically shaped body for a relaxed grip
DynamicDrive Technology
The P30's DynamicDrive technology overcomes signal challenges associated with long cable runs or a mixer’s preamplifier limitations.
Driven by phantom power, the P30’s built-in discrete electronics converts your audio into an ultra-clean amplified signal, keeping mixer preamps in their ‘sweet-spot’ for outstanding audio reproduction.
DynamicDrive Technology
The P30's DynamicDrive technology overcomes signal challenges associated with long cable runs or a mixer’s preamplifier limitations.
Driven by phantom power, the P30’s built-in discrete electronics converts your audio into an ultra-clean amplified signal, keeping mixer preamps in their ‘sweet-spot’ for outstanding audio reproduction.
Optimized for Vocal Performances
Enhanced full-frequency response for stage and studio — whether performing aggressive rock vocals, rhythmic rap freestyle, or precise voice-overs, the P30 will ensure your vocals are clean, intelligible and articulated.
Optimized for Vocal Performances
Enhanced full-frequency response for stage and studio — whether performing aggressive rock vocals, rhythmic rap freestyle, or precise voice-overs, the P30 will ensure your vocals are clean, intelligible and articulated.
Noise Isolation – Stage and Studio
The design of the internal capsule suspension and shock mounting system always ensures handling noise and stage rumble are kept at a minimum.
The P30 will keep the spotlight on your vocals with a cardioid polar pattern providing best off-axis noise rejection coupled with an electronically balanced output.
Noise Isolation – Stage and Studio
The design of the internal capsule suspension and shock mounting system always ensures handling noise and stage rumble are kept at a minimum.
The P30 will keep the spotlight on your vocals with a cardioid polar pattern providing best off-axis noise rejection coupled with an electronically balanced output.
Ergonomically Shaped Body
The P30’s carefully crafted ergonomic grip and elongated balanced body make it easy to handle during extended stage sets, allowing you to concentrate exclusively on your performance.
Ergonomically Shaped Body
The P30’s carefully crafted ergonomic grip and elongated balanced body make it easy to handle during extended stage sets, allowing you to concentrate exclusively on your performance.
Rugged Design & Build
For the highest durability, the P30 uses a precision die-cast zinc body that is nearly indestructible on stage and off.
Its reinforced mesh grille provides enhanced capsule protection from the challenges of tour and performance environments.
Rugged Design & Build
For the highest durability, the P30 uses a precision die-cast zinc body that is nearly indestructible on stage and off.
Its reinforced mesh grille provides enhanced capsule protection from the challenges of tour and performance environments.
Specifications:
Transducer: Dynamic moving coil
Polar Pattern: Cardioid
Frequency Response Range: 50Hz to 18kHz
Sensitivity: 7.08 mV/Pa
Transducer: Dynamic moving coil
Polar Pattern: Cardioid
Frequency Response Range: 50Hz to 18kHz
Sensitivity: 7.08 mV/Pa
Output Impedance: 11.7 Ohms, Electronically Balanced
Optimum Load Impedance: 3k Ohms
Product Length: 7.24 inches. (184mm)
Product Weight: 10.5 oz. (299g)
Optimum Load Impedance: 3k Ohms
Product Length: 7.24 inches. (184mm)
Product Weight: 10.5 oz. (299g)
Specifications:
Transducer: Dynamic moving coil
Polar Pattern: Cardioid
Frequency Response Range: 50Hz to 18kHz
Sensitivity: 7.08 mV/Pa
Output Impedance: 11.7 Ohms, Electronically Balanced
Optimum Load Impedance: 3k Ohms
Product Length: 7.24 inches. (184mm)
Product Weight: 10.5 oz. (299g)
Frequency Response Graph:
Polar Response:
Specifications:
Transducer: Dynamic moving coil
Polar Pattern: Cardioid
Frequency Response Range: 50Hz to 18kHz
Sensitivity: 7.08 mV/Pa
Output Impedance: 11.7 Ohms, Electronically Balanced
Optimum Load Impedance: 3 Ohms
Max SPL: >151dB SPL (1% THD)
Product Length: 7.24 inches. (184mm)
Product Weight: 10.5 oz. (299g)
Frequency Response Graph:
Polar Response:
Specifications:
Transducer: Dynamic moving coil
Polar Pattern: Cardioid
Frequency Response Range: 50Hz to 16kHz
Sensitivity: 2.24 mV/Pa
Output Impedance: 400 Ohms, Transformer Balanced
Typical Load Impedance: >1000 Ohms
Max SPL: >151dB SPL (1% THD)
Product Length: 7.24 inches. (184mm)
Product Weight: 10.6 oz. (301g)
Frequency Response Graph:
Polar Response:
